Key Features
- Automatic conveyor feeding, with an optional hopper feeding system for continuous product supply.
- Automatic flame treatment system to improve ink adhesion and print durability.
- Automatic mechanical pre-registration system for accurate product positioning before printing.
- LED UV or electrode UV curing available to meet different ink and production requirements.
- Multiple product programs can be stored, with one-touch switching between preset screen printing programs for different products.
- Fully enclosed cabinet design provides a clean, professional appearance and a cleaner production environment.
- PLC control with touchscreen operation for simple and intuitive machine setup and operation. Custom programs can be developed to meet specific customer requirements.
- Fully servo-driven motion system with four-axis synchronized control for precise and consistent printing.
- Optional automatic loading and unloading system to reduce manual handling, lower labor requirements, and improve production efficiency.
Applications
The FX01 is suitable for printing on cylindrical products without registration marks, including:
- Whiteboard marker barrels
- Lipstick cases
- Mascara containers
- Cosmetic packaging
- Other cylindrical plastic and glass products
The machine is also suitable for a wide range of round, oval, square, rectangular, triangular, and other irregularly shaped products.
With 360° product positioning and printing, the FX01 can accommodate non-standard product geometries throughout the feeding, printing, and unloading process.
Optional Configuration
- Air blow or vacuum suction can be integrated into the product fixture for secure and stable positioning during printing.
- Automatic loading and unloading system can be added to further automate product handling.
Technical Specifications
| Specification |
FX01 |
| Model |
FX01 |
| Product Diameter |
Φ10–90 mm |
| Product Height |
15–220 mm |
| Maximum Printing Stroke |
300 mm |
| Maximum Screen Frame Size |
250 × 550 mm |
| Power Supply |
220 V, 50 Hz |
| Power Consumption |
1.1 kW |
| Air Pressure |
0.5–0.7 MPa |
| Machine Dimensions |
700 × 750 × 1,700 mm |
| Machine Weight |
Approx. 500 kg |
| Printing Accuracy |
±0.1 mm* |
* Printing accuracy is based on product positioning accuracy and may vary depending on product geometry, material, and printing conditions.
