Key Features
- Automatic conveyor feeding, with an optional hopper feeding system for continuous production.
- Automatic flame treatment system to improve ink adhesion and printing durability.
- Automatic mechanical pre-registration system for accurate product positioning before printing.
- LED UV or electrode UV curing available to suit different ink and production requirements.
- Multiple product programs can be stored, allowing operators to quickly switch between preset screen printing parameters.
- Fully enclosed cabinet design provides a clean, professional appearance and helps maintain a cleaner production environment.
- PLC control with touchscreen operation for simple and intuitive machine setup and operation. Custom programs can be developed according to specific production requirements.
- Fully servo-driven motion system with four-axis synchronized control for precise and consistent printing performance.
- Automatic loading and unloading can be added as an option to reduce labor requirements and increase production efficiency.
Applications
The FX01 is designed for printing on a wide range of round, oval, square, rectangular, triangular, and other irregularly shaped products.
It is particularly suitable for cylindrical products without registration marks, including:
- Whiteboard marker barrels
- Lipstick cases
- Mascara containers
- Cosmetic packaging
- Other irregularly shaped plastic and glass products
The machine supports 360° product positioning and printing across the complete feeding, printing, and unloading process. Actual printing performance may vary depending on product shape, material, and printing requirements.
Optional Configuration
- Air blow or vacuum suction can be integrated into the product fixture for secure and stable positioning.
- Automatic loading and unloading system for increased production efficiency and reduced manual handling.
Technical Specifications
| Specification |
FX01 |
| Model |
FX01 |
| Product Diameter |
Φ10–90 mm |
| Product Height |
15–220 mm |
| Maximum Printing Stroke |
300 mm |
| Maximum Screen Frame Size |
250 × 550 mm |
| Power Supply |
220 V, 50 Hz |
| Power Consumption |
1.1 kW |
| Air Pressure |
0.5–0.7 MPa |
| Machine Dimensions |
700 × 750 × 1,700 mm |
| Machine Weight |
Approx. 500 kg |
| Printing Accuracy |
±0.1 mm* |
* Printing accuracy is based on product positioning accuracy and may vary depending on product geometry, material, and printing conditions.
