Key Features
- Automatic conveyor feeding, with an optional hopper feeding system for continuous product feeding.
- Automatic flame treatment system to improve ink adhesion and print durability.
- Automatic mechanical pre-registration system for accurate product positioning before printing.
- LED UV or electrode UV curing available to meet different production requirements.
- Multiple product programs can be stored, with one-touch switching between preset screen printing programs for different products.
- Fully enclosed cabinet design provides a clean, professional appearance and helps maintain a cleaner production environment.
- PLC control with touchscreen operation provides simple and intuitive machine setup and operation. Customized programs can be developed according to specific customer requirements.
- Fully servo-driven motion system with four-axis synchronized control for precise and consistent printing performance.
- Optional automatic loading and unloading system helps reduce labor requirements and improve production efficiency.
Applications
The FX01 is suitable for printing on cylindrical products without registration marks, including:
- Whiteboard marker barrels
- Lipstick cases
- Mascara containers
- Cosmetic packaging
- Other cylindrical plastic and glass products
The machine can also handle a wide range of round, oval, square, rectangular, triangular, and irregularly shaped products.
It supports 360° product positioning and printing throughout the feeding, printing, and unloading process, making it suitable for a variety of non-standard product shapes and applications.
Optional Configuration
- Air blow or vacuum suction can be integrated into the product fixture for secure and stable positioning during printing.
- Automatic loading and unloading system can be added to reduce manual handling and increase production efficiency.
Technical Specifications
| Specification |
FX01 |
| Model |
FX01 |
| Product Diameter |
Φ10–90 mm |
| Product Height |
15–220 mm |
| Maximum Printing Stroke |
300 mm |
| Maximum Screen Frame Size |
250 × 550 mm |
| Power Supply |
220 V, 50 Hz |
| Power Consumption |
1.1 kW |
| Air Pressure |
0.5–0.7 MPa |
| Machine Dimensions |
700 × 750 × 1,700 mm |
| Machine Weight |
Approx. 500 kg |
| Printing Accuracy |
±0.1 mm* |
* Printing accuracy is based on product positioning accuracy and may vary depending on product geometry, material, and printing conditions.
